定制各式DIP测试插座

	3M™ Textool™ Shrink ZIP DIP Sockets 　 3M™ Textool™ Shrink ZIP DIP Socket is for DIPs with .07 in. lead spacing and accomodates pin counts from 28 through 90 leads.
	3M™ Textool™ Universal ZIP DIP Sockets 　 3M™ Textool™ Universal ZIP DIP Socket is for DIPs with .100 in. lead spacing and has an extra wide contact zone which allows insertion of DIPs with distance between rows from .300 in. through .600 in.
	3M™ Textool™ ZIP DIP Receptacles 　 3M™ Textool™ ZIP DIP Receptacles for all ZIP DIP's Sockets is designed with mounting flanges which hold receptacle to board and has pre-tapped holes in receptacle body mate with screw-hole in socket.
	3M™ Textool™ ZIP DIP Sockets 　 3M™ Textool™ ZIP DIP Socket is for DIPs with .100 in. lead spacing and accomodates pin counts from 14 through 64 leads.

产品型录

Part Number	Pin Count	Pitch(mm)	Description	MFG
228-1290-00-6002J	28	1.778	DIP	3M
232-1291-00-0602J	32	1.778	DIP	3M
242-1293-00-0602J	42	1.778	DIP	3M
256-1292-00-0602J	56	1.778	DIP	3M
264-1300-00-0602J	64	1.778	DIP	3M
290-1294-00-3302J	90	1.778	DIP	3M
224-1286-00-0602J	24	2.54	DIP II	3M
228-1371-00-0602J	28	2.54	DIP II	3M
232-1287-00-0602J	32	2.54	DIP II	3M
240-1288-00-0602J	40	2.54	DIP II	3M
242-1289-00-0602J	42	2.54	DIP II	3M
214-3339-09-0602J	14	2.54	DIP II 底座	3M
216-3340-09-0602J	16	2.54	DIP II 底座	3M
218-3341-09-0602J	18	2.54	DIP II 底座	3M
220-3342-09-0602J	20	2.54	DIP II 底座	3M
222-3343-09-0602J	22	2.54	DIP II 底座	3M
224-1275-09-0602J	24	2.54	DIP II 底座	3M
224-5248-09-0602J	24	2.54	DIP II 底座	3M
228-1277-09-0602J	28	2.54	DIP II 底座	3M
228-1290-09-0602J	28	1.778	DIP II 底座	3M
228-4817-09-0602J	28	2.54	DIP II 底座	3M
240-1280-09-0602J	40	2.54	DIP II 底座	3M
240-3639-09-0602J	40	2.54	DIP II 底座	3M
242-1281-09-0602J	42	2.54	DIP II 底座	3M
242-1293-09-0602J	42	1.778	DIP II 底座	3M
248-1282-09-0602J	48	2.54	DIP II 底座	3M
264-1300-09-0602J	64	1.778	DIP II 底座	3M
264-4493-09-0602J	64	2.54	DIP II 底座	3M
290-1294-09-0602J	90	1.778	DIP II 底座	3M
214-3339-19-0602J	14	2.54	DIP II 底座	3M
216-3340-19-0602J	16	2.54	DIP II 底座	3M
218-3341-19-0602J	18	2.54	DIP II 底座	3M
220-3342-19-0602J	20	2.54	DIP II 底座	3M
222-3343-19-0602J	22	2.54	DIP II 底座	3M
224-1275-19-0602J	24	2.54	DIP II 底座	3M
224-5248-19-0602J	24	2.54	DIP II 底座	3M
228-1277-19-0602J	28	2.54	DIP II 底座	3M
228-4817-19-0602J	28	2.54	DIP II 底座	3M
240-1280-19-0602J	40	2.54	DIP II 底座	3M
240-3639-19-0602J	40	2.54	DIP II 底座	3M
242-1281-19-0602J	42	2.54	DIP II 底座	3M
248-1282-19-0602J	48	2.54	DIP II 底座	3M
264-4493-19-0602J	64	2.54	DIP II 底座	3M
214-3339-00-0602J	14	2.54	DIP II	3M
216-3340-00-0602J	16	2.54	DIP II	3M
218-3341-00-0602J	18	2.54	DIP II	3M
220-3342-00-0602J	20	2.54	DIP II	3M
222-3343-00-0602J	22	2.54	DIP II	3M
224-1275-00-0602J	24	2.54	DIP II	3M
224-5248-00-0602J	24	2.54	DIP II	3M
228-1277-00-0602J	28	2.54	DIP II	3M
228-4817-00-0602J	28	2.54	DIP II	3M
232-1285-00-0602J	32	2.54	DIP II	3M
240-1280-00-0602J	40	2.54	DIP II	3M
240-3639-00-0602J	40	2.54	DIP II	3M
242-1281-00-0602J	42	2.54	DIP II	3M
248-1282-00-0602J	48	2.54	DIP II	3M
264-4493-00-0602J	64	2.54	DIP II	3M
